SP.312646.03 Solar Panel Charge Controller MPPT 3 KiloWatt
$550.00
| Rated Power: | 3000 W |
| Battery Voltage: | 24V/48V |
| Charging Current: | Max. 15A |
| AC Input Range: | 110V : 85 - 138VAC ; 220V : 170 - 275VAC |
| Input Frequency Range: | 50Hz: 46 ~ 54Hz ; 60Hz: 55Hz ~ 65Hz |
| Output Voltage: | Inverter Mode: 110VAC/220VAC +-5% |
| Output Frequency Range: | Inverter Mode: 50Hz/60Hz +-1Hz |
| Output Waveform: | Pure Sine Wave |
| Switching Time: | <10ms |
| Inverter Efficiency: | >85% |
| Overload: | 110-120%/30s ; 150%/3s |
| Protection: | Battery overvoltage and low voltage protection , overload protection , short circuit protection, over temperature protection |
| Display: | LCD + LED |
| Operating Temperature: | 0 - 40 Degrees Celsius |
| Cooling Method: | Forced Air Cooling |
